ASUS TS100-E10-PI4
A-5
Code Description
AC
Reserved for ASL (see ASL Status Codes section below)
AD
Ready To Boot event
AE
Legacy Boot event
AF
Exit Boot Services event
B0
Runtime Set Virtual Address MAP Begin
B1
Runtime Set Virtual Address MAP End
B2
Legacy Option ROM Initialization
B3
System Reset
B4
USB hot plug
B5
PCI bus hot plug
B6
Clean-up of NVRAM
B7
Conguration Reset (reset of NVRAM settings)
B8– BF
Reserved for future AMI codes
D0
CPU initialization error
D1
System Agent initialization error
D2
PCH initialization error
D3
Some of the Architectural Protocols are not available
D4
PCI resource allocation error. Out of Resources
D5
No Space for Legacy Option ROM
D6
No Console Output Devices are found
D7
No Console Input Devices are found
D8
Invalid password
D9
Error loading Boot Option (LoadImage returned error)
DA
Boot Option is failed (StartImage returned error)
DB
Flash update is failed
DC
Reset protocol is not available
ACPI/ASL Checkpoints (under OS)
Code Description
03
System is entering S3 sleep state
04
System is entering S4 sleep state
05
System is entering S5 sleep state
30
System is waking up from the S3 sleep state
40
System is waking up from the S4 sleep state
AC
System has transitioned into ACPI mode. Interrupt controller is in PIC mode.
AA
System has transitioned into ACPI mode. Interrupt controller is in APIC mode.

Asus TS100-E10-PI4 Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
LAN controller	Intel I210-AT, Intel I219LM
Audio chip	Realtek ALC887-VD2
Processor socket	LGA 1151 (Socket H4)
Motherboard chipset	Intel C242
Compatible processor series	Intel Celeron, Intel Core i3, Intel Pentium, Intel Xeon
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Maximum internal memory	128 GB
Supported memory clock speeds	2400, 2666 MHz
PCI slots	2
PCI Express x8 slots	1
PCI Express slots version	3.0
Chassis type	Full-Tower
Cooling type	-
Product type	Workstation barebone
Product color	Black, Metallic
LED indicators	HDD, Power, Reset
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of SATA III connectors	6
RAID levels	0, 1, 5, 10
Storage drive interface	M.2, PCI Express, Serial ATA
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD
On-board graphics card model	Aspeed AST2510
Power supply	500 W
AC input voltage	220 - 240 V
Power supply type	Internal power supply unit
AC input frequency	50 - 60 Hz
AC adapter output current	7 A
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	423 mm
Width	190 mm
Height	435 mm
