Asus TS100-E10-PI4 User Manual

Chapter 1: Product Introduction
1-4
*Specicationsaresubjecttochangewithoutnotice.
Model Name TS100-E10-PI4
Front I/O Ports
2 x USB 3.0 ports
2 x USB 2.0 ports
1 x Headphone port
1 x Microphone port
Rear I/O Ports
2 x USB 3.1 ports
2 x USB 3.0 ports
2 x USB 2.0 ports
1 x VGA Port (onboard Aspeed AST2510)
2 x LAN Ports
3 x Audio Jacks (Realtek
®
ALC887-VD2 8-Channel High Denition
Audio CODEC)
1 x PS/2 Keyboard/ Mouse Port
Switch/LED
Front Switch/LED:
1 x Power switch
1 x Power LED
1 x Reset switch
1 x HDD Access LED
OS Support
Windows
®
Server 2016
Windows
®
10 (TPM needed)
RedHat
®
Enterprise Linux
SuSE
®
Linux Enterprise Server
CentOS
* PleasendthelatestOSsupportfromhttp://www.asus.com/
Management
Solution
Software
ASUS Control Center
Regulatory Compliance
BSMI, CE, RCM, FCC, CCC (Class B)
Dimension (HH x WW x DD)
423mm x 190mm x 435mm
(16.65” x 7.48” x 17.1”)
Net Weight Kg
(Estimated)
12.77 Kg
Gross Weight Kg
(Estimated)
15.74 Kg
Power Supply
(following different
congurationbyregion)
500W 80PLUS Single Power Supply, Gold
Rating: 100-240Vac, 7-3.5A, 50/60Hz, Class I
300W 80PLUS Single Power Supply, Bronze
Rating: 100-127/220-240Vac, 6/3A, 60-50Hz, Class I
Environment
Operating temperature: 10°C ~ 35°C
Non operating temperature: -40°C ~ 70°C
Non operating humidity: 20% ~ 90% ( Non condensing)

Asus TS100-E10-PI4 Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
LAN controller	Intel I210-AT, Intel I219LM
Audio chip	Realtek ALC887-VD2
Processor socket	LGA 1151 (Socket H4)
Motherboard chipset	Intel C242
Compatible processor series	Intel Celeron, Intel Core i3, Intel Pentium, Intel Xeon
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Maximum internal memory	128 GB
Supported memory clock speeds	2400, 2666 MHz
PCI slots	2
PCI Express x8 slots	1
PCI Express slots version	3.0
Chassis type	Full-Tower
Cooling type	-
Product type	Workstation barebone
Product color	Black, Metallic
LED indicators	HDD, Power, Reset
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of SATA III connectors	6
RAID levels	0, 1, 5, 10
Storage drive interface	M.2, PCI Express, Serial ATA
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD
On-board graphics card model	Aspeed AST2510
Power supply	500 W
AC input voltage	220 - 240 V
Power supply type	Internal power supply unit
AC input frequency	50 - 60 Hz
AC adapter output current	7 A
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	423 mm
Width	190 mm
Height	435 mm
