ASUS TS100-E10-PI4
3-3
Layout contents
Internal connectors / Sockets / Jumpers / LEDs
Page
1. ATX power connectors (24-pin EATXPWR1; 8-pin EATX12V1) 3-13
2. CPU, front, and rear fan connectors (4-pin FRNT_FAN1-4; REAR_
FAN1; CPU_FAN1)
3-12
3. DDR4 DIMM sockets 2-9
4. CPU socket 2-4
5. System Management Bus (SMBUS) connector (5-1 pin SMBUS1) 3-17
6. PCH_MFG1 setting (3-pin PCH_MFG1) 3-7
7. ME rmware force recovery setting (3-pin ME_RCVR1) 3-6
8. USB 3.0 connector (20-1 pin USB3_34) 3-11
9. CPU PCIE conguration settings (3-pin U2_CFG5-6) 3-6
10. Serial ATA 6.0Gb/s connectors (7-pin SATA1-6) 3-9
11. Auxiliary panel connector (20-2 pin AUX_PANEL1) 3-15
12. System panel connector (20-1 pin PANEL1) 3-14
13. Serial General Purpose Input/Output connector (6-1 pin SGPIO1) 3-11
14. USB 2.0 connectors (5-1 pin USB14; 10-1 USB78) 3-10
15. Hard disk activity LED connector (4-pin HDLED1) 3-10
16. Chassis intrusion connector (2-pin INTRUSION1) 3-17
17. Trusted Platform Module connector (14-1 pin TPM1) 3-9
18. Clear RTC RAM (3-pin CLRTC1) 3-4
19. LPT connector (26-1 pin LPT1) 3-18
20. Serial port connector (10-1 pin COM1) 3-12
21. Front panel audio connector (10-1 pin AAFP) 3-18
22. Digital audio connector (4-1 pin SPDIF_OUT) 3-19
23. M.2 (NGFF) connector (NGFF1-2) 3-16
24. LAN controller setting (3-pin LAN_SW1) 3-5
25. VGA controller setting (3-pin VGA_SW1) 3-5
