Chapter 3: Motherboard Information
3-6
4. MErmwareforcerecoverysetting(3-pinME_RCVR1)
This jumper allows you to force Intel
®
Management Engine (ME) boot from recovery
mode when ME becomes corrupted.
5. CPUPCIEcongurationsettings(3-pinU2_CFG5-6)
These jumpers allow you to congure the speed at which PCIE6 will run at. Refer to the
table below for the different jumper congurations.
Jumper Setting
U2_CFG6 U2_CFG5 PCIE6slotconguration
21
32
21
32
x16 (Default)
21
32
21
32
x8, x8
21
32
21
32
x8, x4, x4
