ASV RT-40 - Transmission Specifications; Auxiliary Hydraulics Specifications; Ground Pressure; Operating Specifications

3.6 Transmission RT-40
3.7 Auxiliary Hydraulics RT-40
3.8 Ground pressure RT-40
3.9 Operating Specs. RT-40
N
ote: The Maximum Gross Vehicle Weight of the RT-40 is not to exceed 6150 lb
(2790 kg). This includes an operator, accessories, attachments and material being
carried.
3.10 Refill Capacities (approx.) RT-40
Make
Rexroth
Type
A22
Design
Variabledisplacement/axialpistonpump
Displacement
1.71in.³(28.0cc)/revolution
Relief Pressure
5500psi(37,921kPa)
Make
Rexroth
Design
Gear
Displacement
1.16 in. ³ (19 cc) / revolution
Relief pressure
3000 psi (20,684 kPa)
Flow
13.3 gpm (50.4 lpm) @ 2,700 RPM
At operating weight
3.5 psi (24.1 kPa)
Tipping load
2660 lb (1207 kg)
Operating capacity (50% tip load)
1330 lb (603.3 kg)
Operating capacity (35% tip load)
931 lb (422.3 kg)
Fuel tank
13gal(49.2l)
Hydraulic tank
4.5gal(17l)
Engine coolant
1.75gal(6.6l)
Engine oil including filter
7.4qts(7l)
33
3 TECHNICAL DATA
RT-40 US O&M
0404-766 2019-05
