60
5 OPERATION
5.10 Unfastening Attachments (see also section 5.1)
1. Lower the lift arms so that the attachment
is just slightly off of the ground.
2. Pull the locking levers on the quick attach
mechanism upwards and toward the
outside of the machine to unlock the
attachment.
3. Lay the attachment gently onto the ground
by moving the lift arm control joystick
slowly to the right.
4. Once the attachment is in contact with the
ground, move the lift arm control joystick
gently to the right until the quick-attach is
clear of the attachment.
5. Back the machine away from the
attachment.
5.10-1
5.10-3
5.10-2
RT-40 US O&M
0404-766 2019-05
unlock
lock
