4.5 Operator Seat
The RT-40 is available with an
adjustable suspension seat.
To adjust spring preload:
Rotate the knob clockwise for a
heavier operator, counter clock-
wise for lighter operator.
To adjust position (fore/aft):
Move the lever inward toward
the center of the seat, then
slide the seat forward or rear-
ward as needed. Release the
lever to set position
.
To adjust recline:
Rotate the knob clockwise for more recline, counter clockwise for less recline.
4.6 Electric Attachment Control
Attachments for the RT-40 are controlled by pressing various buttons on the joy-
sticks or switches in the cab. Most attachments are controlled hydraulically, but
some require both hydraulic and electrical inputs. The upper 4 buttons on the left
joystick (4.6-1) can send up to 20 amps (combined) of electrical current to pins B,
C, D, G of the receptacle on the lift arms (4.6-1). Attachments requiring electrical
inputs must have a matching receptacle.
Note: The electrical receptacle is not compatible with all attachment brands. Use
only compatible attachments for proper function (see section 4.10).
4 MACHINE DESCRIPTION / CONTROLS
preload
position
41
RT-40 US O&M
0404-766 2019-05
4.6-1
recline
