ATEN CS1734B User Manual

CS1732B / CS1734B User Manual
2
Since a single console manages all of the computers, the CS1732B / CS1734B
installation: 1) eliminates the expense of having to purchase separate console
components for each computer; 2) saves all the space those extra components
would take up; 3) saves on energy costs; and 4) eliminates the inconvenience
and wasted effort involved in constantly moving from one computer to another.
* For PC compatible computers. Mac and Sun computers must use the USB
cable connection (see Cables, page 4).

ATEN CS1734B Specifications

General

HD type	2K Ultra HD
Scan interval	1, 3, 4, 5, 8, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 80, 90, 99, 100, 240, 250, 255 s
Video bandwidth	60 Hz
Maximum resolution	2048 x 1536 pixels
Firmware upgradeable	Yes
Headphone outputs	5
USB connector type	USB Type-A
Number of computers controlled	4
Product color	Black, Grey
LED indicators	Activity, USB
Housing material	Metal
Wired remote switch	No
Power source	DC
Output voltage	5.3 V
Power consumption (typical)	3.4 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
Harmonized System (HS) code	85176200

Weight and Dimensions

Depth	88 mm
Width	210 mm
Height	55.5 mm
Weight	780 g
