ATEN CS1734B User Manual

CS1732B / CS1734B User Manual
26
Hotkey Summary Table
[Num Lock] + [-] [Enter] Brings the KVM, USB hub, and audio focus from
the port that currently has the KVM focus to the
next port on the installation.
[Port ID]
[Enter]
Switches access to the computer that corresponds
to that Port ID.
[K] or [U] or
[S] [Enter]
Brings only the KVM or USB hub or audio focus
from the port that currently has it to the next port
on the installation.
[Port ID] [K] or
[U] or [S]
Brings the KVM or USB hub or audio focus to the
computer attached to the corresponding port.
[A] [n] Sets the Auto Scan interval to n seconds – where
n is a number from 1–255.
[A] Invokes Auto Scan Mode.
[←] Invokes Skip Mode and Skips from the current port
to the first accessible port previous to it.
[→] Invokes Skip Mode and Skips from the current port
to the next accessible port.
[↑] Invokes Skip Mode and Skips from the current port
to the last accessible port of the previous Station.
[↓] Invokes Skip Mode and Skips from the current port
to the first accessible port of the next Station.
[D] Invokes Video DynaSync so the CS1732
B /
CS1734
B stores the console monitor’s EDID.
[F4] Lists the current OSD settings via the Paste
function of a text editor, including
a) Hotkey
b) OSD Hotkey
c) Port OS
d) Mouse Emulation
e) Button Settings
[F5] Performs USB Keyboard and Mouse reset.
[H] Toggles between the default and alternate HSM
invocation keys.
[T] Toggles between the default and alternate OSD
Invocation keys.

ATEN CS1734B Specifications

General

HD type	2K Ultra HD
Scan interval	1, 3, 4, 5, 8, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 80, 90, 99, 100, 240, 250, 255 s
Video bandwidth	60 Hz
Maximum resolution	2048 x 1536 pixels
Firmware upgradeable	Yes
Headphone outputs	5
USB connector type	USB Type-A
Number of computers controlled	4
Product color	Black, Grey
LED indicators	Activity, USB
Housing material	Metal
Wired remote switch	No
Power source	DC
Output voltage	5.3 V
Power consumption (typical)	3.4 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
Harmonized System (HS) code	85176200

Weight and Dimensions

Depth	88 mm
Width	210 mm
Height	55.5 mm
Weight	780 g
