ATEN CS1734B User Manual

4. Keyboard Port Operation
23
Skip Mode
This feature allows you to switch between computers in order to monitor them
manually. You can dwell on a particular port for as long or as little as you like
– as opposed to Auto Scanning, which automatically switches after a fixed
interval. To invoke Skip Mode, key in the following Hotkey combination:
1. Invoke HSM (see page 19).
2. Key in [Arrow]
 Where [Arrow] refers to one of the Arrow keys. After you press
[Arrow], you automatically exit Hotkey Mode, and enter Skip Mode
where you can switch ports as follows:
 Once you are in Skip Mode, you can keep on skipping by pressing the
Arrow keys. You don't have to use the [NumLock] + [-] combination
again.
 While Skip Mode is in effect, ordinary keyboard and mouse functions
are suspended – only Skip Mode compliant keystrokes can be input.
You must exit Skip Mode in order to regain normal control of the
console.
3. To exit Skip Mode, press [Esc] or [Spacebar].
← Skips from the current port to the first accessible port previous to it.
→ Skips from the current port to the next accessible port.
↑
Skips from the current port to the last accessible port of the previous
Station.
↓
Skips from the current port to the first accessible port of the next
Station.

ATEN CS1734B Specifications

General

HD type	2K Ultra HD
Scan interval	1, 3, 4, 5, 8, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 80, 90, 99, 100, 240, 250, 255 s
Video bandwidth	60 Hz
Maximum resolution	2048 x 1536 pixels
Firmware upgradeable	Yes
Headphone outputs	5
USB connector type	USB Type-A
Number of computers controlled	4
Product color	Black, Grey
LED indicators	Activity, USB
Housing material	Metal
Wired remote switch	No
Power source	DC
Output voltage	5.3 V
Power consumption (typical)	3.4 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
Harmonized System (HS) code	85176200

Weight and Dimensions

Depth	88 mm
Width	210 mm
Height	55.5 mm
Weight	780 g
