ATEN CS1784A User Manual

Appendix
47
Function CS1784A
Computer Connections 4
Port Selection Front Panel Pushbuttons, Hotkeys, Mouse
Connectors
Console
Port
s
Keyboard 1 x USB Type-A Female (Black; rear panel)
Video 1 x DVI-I Female (white)
Mouse 1 x USB Type-A Female (Black; rear panel)
Audio Speaker 2 x Mini Stereo Jack Female (Green; 1 x front panel, 1
x rear panel)
Microphone
2 x Mini Stereo Jack F (Pink; 1 x front panel, 1 x rear
panel)
KVM
Ports
Keyboard/Mouse 4 x USB Type-B Female (White)
Video 4 x DVI-I F (White)
Audio Speaker 4 x Mini Stereo Jack Female (Green)
Microphone
4 x Mini Stereo Jack Female (Pink)
Power 1 x DC Jack
USB 2.0 Hub 2 x USB Type-A Female (White; 1 x front panel, 1 x
rear panel)
Switches Selected 4 x Pushbutton
LEDs On Line / Selected 4 (Orange)
USB Link 4 (Green)
Emulation Keyboard / Mouse USB
Video Dual Link DVI: 2560 x 1600
Single Link DVI: 1920 x 1200
Scan Interval 1–99 secs. (5 secs. default)
Power Consumption DC 5.3V, 5.91W
Environment
Operating Temp. 0–50ºC
Storage Temp. -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.93 kg
Dimensions (L x W x H) 27.00 x 8.80 x 5.55 cm
