CS1782 A / CS1784 A User Manual
46
Specifications
Function CS1782A
Computer Connections 2
Port Selection Front Panel Pushbuttons, Hotkeys, Mouse
Connectors
Console
Ports
Keyboard 1 x USB Type-A Female (Black; rear panel)
Video 1 x DVI-I Female (white)
Mouse 1 x USB Type-A Female (Black; rear panel)
Audio Line out 2 x Mini Stereo Jack Female (Green; 1 x front
panel, 1 x rear panel)
Line In 1 x Mini Stereo Jack Female (Blue)
Side Speaker out
1 x Mini Stereo Jack Female (Gray)
Rear Speaker out
1 x Mini Stereo Jack Female (Black)
Center/Subwoofer
1 x Mini Stereo Jack Female (Orange)
Microphone
2 x Mini Stereo Jack F (Pink; 1 x front panel, 1 x
rear panel)
KVM
Ports
Keyboard/Mouse 2 x USB Type-B Female (White)
Video 2 x DVI-I F (White)
Audio Line out 2 x Mini Stereo Jack Female (Green)
Line In 2 x Mini Stereo Jack Female (Blue)
Side Speaker out
2 x Mini Stereo Jack Female (Gray)
Rear Speaker out
2 x Mini Stereo Jack Female (Black)
Center/Subwoofer
2 x Mini Stereo Jack Female (Orange)
Microphone 2 x Mini Stereo Jack Female (Pink)
Power 1 x DC Jack
USB 2.0 Hub 2 x USB Type-A Female (White; 1 x front panel,
1 x rear panel)
Switches Selected 2 x Pushbutton
LEDs On Line / Selected 2 (Orange)
USB Link 2 (Green)
Emulation Keyboard / Mouse USB
Video Dual Link DVI: 2560 x 1600
Single Link DVI: 1920 x 1200
Scan Interval 1–99 secs. (5 secs. default)
Power Consumption DC 5.3V, 3.3W
Environment
Operating Temp. 0–50ºC
Storage Temp. -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.90 kg
Dimensions (L x W x H) 27.00 x 8.80 x 5.55 cm
