Chapter 6. The Firmware Upgrade Utility
41
Upgrade Succeeded
After the upgrade has completed, a screen appears to inform you that the
procedure was successful:
Click Finish to close the Firmware Upgrade Utility.
After a successful completion, the CS1782
A
/ CS1784
A
exits Firmware
Upgrade Mode, and resets itself.
Upgrade Failed
If the Upgrade Succeeded screen doesn’t appear, it means that the upgrade
failed to complete successfully, in which case you should do the following:
1. Power off the CS1782
A
/ CS1784
A
by removing the power jack.
2. Invoke Firmware Upgrade Mode by holding down the port 1 selection
pushbutton in the front panel (see Components, page 7) and power on the
CS1782
A
/ CS1784
A
. The orange LEDs flash together.
3. Do the firmware upgrade procedure again.
cs1782a-1784a.book Page 41 Monday, July 19, 2021 4:50 PM
