11
Chapter 2
Hardware Setup
Cable Connections
To set up your CS1782
A
/ CS1784
A
installation, refer to the installation
diagram on the following page (the numbers in the diagrams correspond to the
steps, below), and do the following:
1. Plug your USB keyboard and USB mouse into the USB console ports
located on the unit’s rear panel.
2. Plug your console monitor into the DVI console port located in the unit’s
rear panel and power on the monitor.
3. Plug your main microphone and speakers into the console microphone and
speaker jacks located on the unit’s front panel. The microphone and
speakers plugged into this panel have priority over those in the rear panel.
4. Plug your secondary microphone and 2.1 / 7.1 speakers into the console
audio ports located on the unit’s rear panel.
4a. Plug one end of the 7.1 surround sound cable provided with the
package into the 7.1 channel audio ports on the CS1782
A
1. Important safety information regarding the placement of this
device is provided on page 43. Please review it before
proceeding.
2. To prevent damage to your installation from power surges or
static electricity. It is important that all connected devices are
properly grounded.
3. Make sure that power to all the devices you will be installing has
been turned off. You must unplug the power cords of any
computers that have the Keyboard Power On function.
4. Please operate the device with caution when under high
environmental temperatures, as the surface of the device may
become overheated under such conditions. For instance, the
surface temperature of the device may reach 70 °C (158 °F) or
higher when the environmental temperature reaches close 50 °C
(122 °F).
cs1782a-1784a.book Page 11 Monday, July 19, 2021 4:50 PM
