CS1782
A
/ CS1784
A
User Manual
12
4b. Plug the other end of the 7.1 surround sound cable into the 7.1 channel
audio ports on your computer.
5. Using a KVM cable set (provided with this package), plug the DVI
connector into any available DVI socket in the KVM port section of the
switch, then plug the accompanying USB, microphone and speaker
connectors into their corresponding USB, microphone, and speaker
sockets.
Note: Verify that all the plugs are in the same KVM port sockets (all in port
1, all in port 2, etc.). Each socket is marked with an appropriate icon.
6. At the other end of the cable, plug the USB, video, microphone, and
speaker cables into their respective ports on the computer.
7. Plug your USB peripherals into the USB Type-A ports in the USB hub
section.
8. Plug the power adapter that came with your switch into an AC power
source, then plug power adapter cable into the switch’s power jack.
9. Power on the computers.
Note: Make sure the computers and devices that the CS1782A / CS1784A
connects to are also properly grounded.
cs1782a-1784a.book Page 12 Monday, July 19, 2021 4:50 PM
