ATEN CS1784A User Manual

Chapter 4. Hotkey Operation
21
Going Directly to a Port
Note: The n stands for the computer’s Port ID number (1, 2, 3, or 4). See Port
ID Numbering, page 17. Replace the n with the appropriate Port ID
when entering hotkey combinations.
Example 1
To bring the KVM, USB hub, and audio focus from a port to a specified port
number (e.g., port 2), do the following:
1. Press [Scroll Lock] twice.
2. Press [2].
3. Press [Enter].
Hotkey Action
[Scroll Lock] [Scroll Lock]
[n] [Enter]
Brings the KVM, USB hub, and audio focus to the
computer attached to the port corresponding to the
specified Port ID.
Note: The KVM, USB hub, and audio focus all go to this
port even if they were on different ports to begin with.
[Scroll Lock] [Scroll Lock]
[n] [K] [Enter]
Brings only the KVM focus to the computer attached to
the specified port. The USB hub and audio focus remain
where they are.
[Scroll Lock] [Scroll Lock]
[n] [U] [Enter]
Brings only the USB hub focus to the computer
attached to the specified port. The KVM and audio focus
remain where they are.
[Scroll Lock] [Scroll Lock]
[n] [S] [Enter]
Brings only the audio focus to the computer attached to
the specified port. The KVM and USB hub focus remain
where they are.
[Scroll Lock] [Scroll Lock]
[n] [K] [U] [Enter]
Brings the KVM and USB hub focus to the computer
attached to the specified port. The audio focus remains
where it is.
[Scroll Lock] [Scroll Lock]
[n] [K] [S] [Enter]
Brings the KVM and audio focus to the computer
attached to the specified port. The USB hub focus
remains where it is.
[Scroll Lock] [Scroll Lock]
[n] [U] [S] [Enter]
Brings the USB hub and audio focus to the computer
attached to the specified port. The KVM focus remains
where it is.
cs1782a-1784a.book Page 21 Monday, July 19, 2021 4:50 PM
