ATEQ F28+ User Manual

QSG_F28+.394.00_EN_01 / 2019-02-25
38 / 42
CONFIGURATION menu
Use this menu to configure your ATEQdevice.
Label Function Description
LANGUAGE
Language Selection of the language displayed on the screen
PNEUMATIC
Pneumatics Configuration of the pneumatics functions of the device
>AUTO VOL
- Configuration of volume calculation for automatic
program selection (option)
>ELEC. REG.
- Activation of the electronic regulator
>REGUL. CTRL.
- Configuration of the electronic regulator (external or
auto) (option)
>PERM. REG.
- The electronic regulator is active every time
>PIEZO AUTO AZ
- Configuration the frequency of the auto zero
>AZ SHORT
- Deactivation of the linearization of the regulator during
the auto zero process (option)
>Press. UNIT
- Pressure unit by default for the new programs
>DUMP LEVEL
- Configuration of the minimum dump level pressure
>LINE P. MIN
- Minimum level for checking line pressure (option)
>BLOW MODE
- Blowing mode when test cycle is not running (option)
>EXT. DUMP
- Configuration of the external dump (option)
>DUMP OFF
- Remove dump time parameter on the selected program
that becomes 0 second
AUTOMATISM
Automatism Configuration of the different communications between
the device and its environment
>RS232
- Configuration of the communication type on the RS232
port
>USB
- Configuration of the connection type on the USB port
>Date & Time
- Setup of the built-in clock
>OUTPUTS CONFIG.
- Configuration of the programmable outputs
>INPUTS CONFIG.
- Configuration of the programmable inputs
>CODE READER
- Bar code reader configuration
SECURITY
Security Security functions
>ACCESS
- Parameters access mode (key or password)
>START OFF
-
Deactivation of the Start
on the instrument front
panel. Programs can only be started from the instrument
relay board.
MISCELLANEOUS
Miscellaneous
>SMART KEY
- Configuration of the assigned function to the
Smart key
