Line Function Setting range
or display
Setting
increment
Basic
setting
Heating adjustment
65 U Reduced setpoint frost protection setpoint (67)…
comfort setpoint
0,5 °C 19 °C
66 I Heating curve slope see gure 36. 0,1... 4 0,02 °C 0,5 °C
67 U Frost protection setpoint 4 °C… reduced setpoint 0,5 °C 8 °C
68 I Heating curve displacement -4,5 °C... 4,5 °C 0,5 °C 0 °C
69 I Summer/Winter heating limits 8 °C... 30 °C 0,5 °C 18 °C
When the average of the outdoor temperatures over the past 24 hours reaches 18°C, the regulator switches off the
heating (as an economy measure).
70 I Flow temp. setpoint maxi 8... 95 °C 1 °C 55 °C
Floor heating system = 50 °C.
Remark : Maximum temperature limitation is not a safety function as required by ground heating.
71 I Flow temp. setpoint mini 8... 95 °C 1 °C 8 °C
72 I Heating curve adaption (see § 3.3.2) 0 : Off, 1 : On 0
73 I Room inuence 1 %... 100 % 1 % 50 %
If the installation is tted with an room sensor:
This function enables you to choose the ambient temperature's inuence on the setting.
If no value is entered, the setting is made based on the outdoor temperature.
If the parameter is set at 100%, the setting is only based on the ambient temperature.
74 I Mean outside temperature -50... 50 °C -
Reset : Press the button (+/OK) 2 times.
This is the average of the outdoor temperature over a 24-hour period. This value is used for automatic Summer / Winter
switchover (line 69).
DHW setting (domestic hot water) (Only with the DHW kit option)
75 U Pre-selection (day / week) 1-7 : Mon-Sun, 1-5 : Mon-Fri,
6-7 : Sat-Sun, 1 : Monday, ... ,
6 : Sathurdayi, 7 : Sunday
1-7
76 U 1st phase On (start) 00:00... 24:00 10 min 0:00
77 U 1st phase Off (end) 00:00... 24:00 10 min 5:00
78 U 2nd phase On (start) 00:00... 24:00 10 min 14:30
79 U 2nd phase Off (end) 00:00... 24:00 10 min 17:00
80 U 3rd phase On (start) 00:00... 24:00 10 min --:--
81 U 3rd phase Off (end) 00:00... 24:00 10 min --:--
82 I Lower DHW temperature setting 8 °C... Nominal setting 1 40 °C
83 I DHW release 0 : 24h/day,
1 : Time programs HCs,
2 : Time program /DHW,
3 : Low-tariff,
4 : T'prog /DHW or low-tariff
2
(0) 24h/day : The temperature of the DHW is constantly maintained at the DHW nominal setting.
(1) Time programs HCs : The DHW is produced according to the programming for the ambient temperature
(with 1 hour in advance when switched on).
(2) Time program /DHW : The DHW programme is separate form the heating circuit programme.
(3) Low-tariff * : The electrical backup heating is only authorised to operate during the off-peak period.
(4) T'prog /DHW or low-tariff * : The electrical backup heating is authorised to operate during the nominal period or off-peak.
* - Connect the "Power Provider" contact to input EX2 (E5). (see gure 33, page 28). In the case of a day /night contract,
the electric back-ups for the DHW tank are subject to the power supplier's tariffs. Switching on the electric back-up for
the DHW tank is only authorised during off-peak hours.
Installation and operation manual "1397 - EN" - 35 -
Heat pump split single service alféa Evolution
