3.5 Information display
Various data can be displayed by pressing the info
button.
Depending on the type of unit, conguration and
operating state, some of the info lines listed below may
not appear.
- Possible error messages from the error code list
(see table, page 48).
- Possible service messages from the maintenance
code list.
- Possible special mode messages.
- Various data (see below).
Designation Line
Time. 1
Room temperature. 2
Outdoor temperature. 3
DHW temperature. 4
HP ow temperature. 5
HP return temperature. 6
Setpoint HP (ow). 7
Room setpoint. 8
Outdoor temp composite. 9
State heat pump. 11
Heat pump power modulation,% . 12
State supplementary source. 13
State DHW. 14
State heating circuit. 15
Function not used 16
3.5.1 Status list
Designation Nr
State heating circuit (line15)
Active manual intervention. 4
Controlled active drying. 102
Restriction of heating regime. 106
Forced draught. 110
Heating regime, comfort. 114
Heating regime, low. 116
Frost protection active. 24
Summer regime. 118
Off. 25
State DHW (line 14) (if DHW kit)
Active manual intervention. 4
Fluid decanting regime. 199
Adiabatic cooling active. 53
Load locking active. 82
Forced load active. 67
Electrical resistance load. 66
Accelerated load active. 94
Load active. 69
Frost protection active. 24
Delayed power-cut response active. 17
Load on standby. 201
Under load. 75
Off. 25
Ready. 200
Designation Nr
State heat pump (line 11)
Emergency operation. 26
Fault. 2
Locked. 10
Time limit active. 37
Frost protection active. 24
Defrost activated. 125
Active cooling regime. 127
Heating. 137
Passive cooling regime. 128
Off. 25
