1 Description of the unit
1.1 Package
• 1 package: outdoor unit.
• 1 package: hydraulic unit and outdoor sensor.
1.2 Denitions
- Split: The heat pump consists of two elements (an
outdoor unit for outdoor and a hydraulic unit for inside
the dwelling).
- Air/water: The surrounding air is the energy source.
This energy is transmitted to the water in the heating
circuit by the heat pump.
- Inverter: the fan and compressor speeds are
modulated according to the heating requirements.
This technology enables you to save on energy and
operate on a single-phase power supply, whatever the
heat pump's output, by avoiding heavy intensities on
start-up.
- COP (coefcient of performance): this is the relationship
between the energy transmitted to the heating circuit
and electrical energy consumed.
Packing list
Heat pump Outdoor unit Hydraulic unit
Model Code Model Code Model Code
alféa Evolution 5 522324 AOYA 18 LALL 700718 alféa Evolution 5 023146
alféa Evolution 6 522325 AOYA 18 LALL 700718
alféa Evolution
6-16
023140
alféa Evolution 8 522326 AOYA 24 LALL 700724
alféa Evolution 10 522327 AOYA 30 LBTL 700730
alféa Evolution 13 522328 AOYA 45 LBTL 700845
alféa Evolution 16 522329 AOY 54 LJBYL 700054
Scope of application
This heat pump provides:
- Heating in winter,
- Production of domestic hot water* (provided that
combined with a DHW tank).
- Installation with boiler connection* as a supplementary
heating for the coldest days.
or
- the addition of electrical back-ups, for extra heating on
the coldest days.
* : These options require the use of additional kits
(see para "Optional equipment").
Optional equipment
• DHW kit (code. 073991)
for connecting a DHW tank
(with built-in electrical back-ups).
• Boiler connection kit (code 073989)
for connecting a boiler to the heat pump.
• Electrical back-ups kit (code 073985).
• Room thermostat T37 (code 075308),
Room thermostat T55 (code 073951)
for correcting the ambient temperature.
• Room control unit T75 (code 073954),
Room control unit radio T78 (code 074061)
for correcting the ambient temperature and
programming the heat pump.
• Anti-vibration blocks (code 523574).
• White PVC oor support (code 809532).
• High ow rate circulating pump kit (code 074067)
for the installation of 1 circuit oor heating.
