7.4 Start-up data sheet
Site Installer
Outdoor unit
Serial Nr.
Hydraulic unit
Serial Nr.
Model Model
Refrigerant type Refrigerant charge kg
Checks Operating voltage & current on outdoor unit
Compliance with positioning distances L/N V
Condensate evacuation correct
Electric connections / connections tightnees L/T V
No GAS leaks
(unit ID Nr. : )
Installation of refrigeration connection correct (lenght : m) N/T V
Reading in HEATING operating mode
Compressor discharge temp. °C Icomp A
Liquid line temp. °C
}
}
}
Condensation temp. HP = bar °C sub-cooling °C
Tank water output temp. °C ΔT condensation °C
Tank water input temp. °C ΔT secondary °C
Evaporation temp. BP = bar °C
}
}
}
Suction temp. °C Overheating °C
Battery air input temp. °C ΔT evaporation °C
Battery air output temp. °C ΔT battery °C
Hydraulic system of hydraulic unit
Secondary system
Floor heating system
Circulator brand TypeLow temp. radiator
Fan convector
Domestic hot water ; tank type
Estimated water volume of secondary system L
Options & Accessories :
Power supply for connected electric auxiliary Room thermostat T 37
Room thermostat T 55
Location of room sensor correct Room control unit T75
Room control unit T78
DHW kit Details
Boiler connection kit
Control settings
Conguration type
Essential settings
Installation and operation manual "1397 - EN" - 53 -
Heat pump split single service alféa Evolution
