Line Function Setting range
or display
Setting
increment
Basic
setting
Heating adjustment, circuit 1
710 U Comfort setpoint Reduced setpoint…
Comfort setpoint maximum
0,5 °C 20 °C
712 U Reduced setpoint Frost protection setpoint…
Comfort setpoint
0,5 °C 19 °C
714 U Frost protection setpoint 4 °C… Reduced setpoint 0,5 °C 8 °C
716 S Comfort setpoint maximum 20 °C... 35 °C 1 °C 28 °C
720 I Heating curve slope 0,1... 4 0,02 0,5
(see chapter 7.4.3, page 50 & gure 45, page 49)
721 I Off-set of the heating curve (gure 46, page 49) -4,5 °C... 4,5 °C 0,5 °C 0
730 I Summer / Winter heating limits 8 °C... 30 °C 0,5 °C 18 °C
When the average of the outdoor temperatures over the past 24 hours reaches 18°C, the regulator switches off the heating
(as an economy measure). During summer mode, the display shows "Eco". This function is only active in automatic mode.
740 I Flow temp setpoint min 8 °C... Flow temp setpoint max 1 °C 17 °C
(with dynamic radiator, adjust from 30 to 35°C)
741 I Flow temp setpoint max Flow temp setpoint min... 70 °C 1 °C 55 °C
Floor heating system = 50 °C / Radiators = 65 °C.
Important Note : Maximum temperature limitation is not a safety function as required by ground heating.
750 S Room inuence 1%... 100% 1% 50%
If the installation is tted with a room thermostat:
This function enables you to choose the ambient temperature's inuence on the setting.
If no value is entered, the setting is made based on the temperature control.
If the parameter is set at 100%, the setting is only based on the ambient temperature.
760 S Room temperature limitation 0,5... 4 °C 0,5 °C 0,5 °C
As soon as the room temperature = [Setpoint line 710 (ex. 20°C) + Room temperature limitation setpoint line 760
(ex. 0,5 °C)] > 20,5 °C => The heat pump is stopped.
It restarts when the room temperature falls below the setpoint (in the example, Room temperature < 20,0 °C).
780 S Quick setback Off, Down to reduced setpoint,
Down to frost prot setpoint
Off
790 S Optimum start control max
(Early start to switch to the comfort setting.)
0... 360 min 10 min 180 min
791 S Optimum stop control max (Early stop to switch from
the comfort setting to the reduced setting.)
0... 360 min 10 min 30 min
800 S Reduced setpoint increase start -30... 10 °C 1 °C --
801 S Reduced setpoint increase end -30... 10 °C 1 °C -5 °C
830 S Mixer valve boost 0... 50 °C 1 °C 0 °C
834 S Actuator running time 30... 873 s 1 s 240 s
