I. Technical specications
I.1 Vertical wall-mounted water heater (VW)
*Appliances supplied with three-phase wiring 230/400V3~ can be switched to 230 V single-phase~
**Real heating time for heating from 15° to 65°C
***Maintenance consumption in kWh for 24 hours for water at 65°C (ambiance 20°C)
Technical specications
50 litres 75 litres 100 litres
Voltage (V) 230 V single-phase
Resistance Shielded Steatite Shielded Steatite Shielded Steatite
Power (W) 1,200 1,200 1,200 1,200 1,200 1,200
Dimensions
(mm)
Ø 505 505 510 510 505 510
H 575 575 700 700 910 865
A 370 370 575 575 750 750
B / / / / / -
C 530 530 530 530 530 530
Real heating time** 2 h 26 min 2 h 46 min 4 h 10 min 4h 10 min 5 h 29 min 5 h 46 min
Qpr (Maintenance consumption) *** 0.71 0.79 1.00 1.00 1.24 1.33
V40 (Amount of hot
water at 40°C)
- - 141 141 179 192
Weight when empty (kg) 23 23 26 26 32 30
Weight when full (kg) 73 73 101 101 130 130
150 litres 200 litres 200 litres
Voltage (V) 230 V single-phase All currents*
Resistance Shielded Steatite Shielded Steatite Shielded
Power (W) 1,650 1,800 2,200 2,200 2,200
Dimensions
(mm)
Ø 530 530 530 530 530
H 1,165 1,165 1,480 1,480 1,480
A 1,050 1,050 1,050 1,050 1,050
B 800 800 800 800 800
C 550 550 550 550 550
Real heating time** 5 h 33 min 5 h 33 min 5 h 17 min 5 h 17 min 5 h 17 min
Qpr (Maintenance consumption) *** 1.48 1.48 1.73 1,73 1.73
V40 (Amount of hot
water at 40°C)
279 279 382 382 382
Weight when empty (kg) 38 38 46 46 46
Weight when full (kg) 188 188 246 246 246
