Your water heater: Wiring diagrams
II. Presentation of the components
II.1 Components making up the shielded vertical wall-mounted models
II.2 Components making up Steatite vertical wall-mounted models
II.3 Components making up vertical versions on shielded base
Thermal safety
mechanism
Cold water
inlet
Thermostat
Power supply cable
Hot water outlet
Thermal safety
mechanism
Thermostat
Power supply cable
230 V Single-phase All currents
Heater element
Power supply cable
Thermostat
Thermal safety
mechanism
