Procedure
Step Action
1 Stop the compressor, close the air outlet valve and switch off the voltage. Wait a few
minutes and depressurise by unscrewing plug (4) only one turn to permit any pressure in
the system to escape.
2 Use an oil pan to avoid possible oil spillage. Unscrew oil filters (3) only one turn and wait
a few minutes to let the oil of the filter flow back into the oil separator. Remove the oil filters.
3 Clean the filter seats on the manifold. Oil the gaskets of the new filters and screw the filters
into place until the gaskets contact their seats. Then tighten by hand.
4 Tighten plug (4).
5 Reset the message and service timer:
•
Press the “Menu” key (3).
•
Press key (1) until “Service” is followed by an arrow pointing to the right. Activate the
menu by pressing key (2).
•
Press key (1) until “Oil filter” is followed by an arrow pointing to the right. Activate the
menu by pressing key (2).
•
Press the “Reset” key (3); the timer is reset to 0.
6.6 Storage after installation
Procedure
Run the compressor, e.g. twice a week, until warm. Load and unload the compressor a few times to operate
the components of the unloading/loading system.
If the compressor is going to be stored without running from time to time, protective
measures must be taken. Consult the Atlas Copco Customer Centre.
6.7 Service kits
General
Service kits comprise all parts needed for servicing components and offer the benefits of genuine Atlas Copco
parts while keeping the maintenance budget low. All service kits are indicated in the relevant Parts Lists.
Atlas Copco Roto-Inject Fluid
Roto-Inject Fluid can be ordered in the following quantities:
• 20-litre can: 2901 0522 00
• 209-litre drum: 2901 0045 01
See the section Oil specifications.
Instruction book
2920 1475 06 101
