Minimum
setting
Factory
setting
Maximum
setting
Loading pressure, 8.6 bar compressor bar(e) 4.5 8.0 9.105
Loading pressure, 125 psi compressor psig 65.3 91.4 132.1
Loading pressure, 10.4 bar compressor bar(e) 4.5 9.7 10.805
Loading pressure, 150 psi compressor psig 65.3 140.7 156.7
Loading pressure, 13.8 bar compressor bar(e) 4.5 12.7 13.805
Loading pressure, 200 psi compressor psig 65.3 184.2 200.2
Protection settings for GA90 up to GA250 and GA315 60 Hz
Minimum
setting
Factory
setting
Maximum
setting
Compressor outlet pressure (shut-down
warning level)
bar 0 16.5 17.0
Compressor outlet pressure (shut-down
warning level)
psi 0 239.3 246.5
Compressor outlet pressure (shut-down
level)
bar 0 17.0 17.0
Compressor outlet pressure (shut-down
level)
psi 0 246.5 246.5
Oil injection pressure, element (start
protection)
bar 2.0 2.5 13.2
Oil injection pressure, element (start
protection)
psi 29 36.2 191.4
Compressor outlet temperature (without DD
filter) (shut-down warning level)
˚C 0 66 120
Compressor outlet temperature (without DD
filter) (shut-down warning level)
˚F 32 150.8 248
Compressor outlet temperature (without DD
filter) (shut-down level)
˚C 0 80 120
Compressor outlet temperature (without DD
filter) (shut-down level)
˚F 32 176 248
Compressor outlet temperature (with DD
filter) (shut-down warning level)
˚C 0 66 100
Compressor outlet temperature (with DD
filter) (shut-down warning level)
˚F 32 150.8 212
Compressor outlet temperature (with DD
filter) (shut-down level)
˚C 0 80 100
Compressor outlet temperature (with DD
filter) (shut-down level)
˚F 32 176 212
Compressor outlet temperature (delay at
signal)
sec 5 5 5
Compressor element outlet temperature
(shut-down warning level) (without energy
recovery)
˚C 80 100 110
Instruction book
2920 1475 06 51
