Compressor Supply voltage Cable size
GA 110 400 V
2x (3x70 mm
2
+35 mm
2
)
GA 110 500 V
2x (3x50 mm
2
+25 mm
2
)
GA 132 230 V
2x (3x240 mm
2
+120 mm
2
)
GA 132 400 V
2x (3x95 mm
2
+50 mm
2
)
GA 132 500 V
2x (3x70 mm
2
+35 mm
2
)
GA 160 230 V
4x (3x95 mm
2
+50 mm
2
)
GA 160 400 V
2x (3x120 mm
2
+70 mm
2
)
GA 160 500 V
2x (3x95 mm
2
+50 mm
2
)
GA 200 400 V
2x (3x185 mm
2
+95 mm
2
)
GA 200 500 V
2x (3x120 mm
2
+70 mm
2
)
GA 250 400 V
2x (3x240 mm
2
+120 mm
2
)
GA 250 500 V
2x (3x150 mm
2
+70 mm
2
)
GA 90 up to GA 315 60 Hz and GR 60 Hz IEC compressors
Compressor Supply voltage Cable size
GA 90 220 - 230 V
2x (3x150 mm
2
+70 mm
2
)
GA 90 380 V
2x (3x70 mm
2
+35 mm
2
)
GA 90 440 - 460V
2x (3x50 mm
2
+25 mm
2
)
GA 110 220 - 230 V
2x (3x185 mm
2
+95 mm
2
)
GA 110 380 V
2x (3x95 mm
2
+50 mm
2
)
GA 110 440 - 460V
2x (3x70 mm
2
+35 mm
2
)
GA 160 380 V
2x (3x120 mm
2
+70 mm
2
)
GA 160 440 - 460V
2x (3x95 mm
2
+50 mm
2
)
GA 200 380 V
2x (3x185 mm
2
+95 mm
2
)
GA 200 440 - 460V
2x (3x150 mm
2
+70 mm
2
)
GA 250 380 V
2x (3x240 mm
2
+120 mm
2
)
GA 250 440 - 460V
2x (3x185 mm
2
+95 mm
2
)
GA 315 380 V
4x (3x95 mm
2
+50 mm
2
)
GA 315 440 - 460V
2x (3x240 mm
2
+120 mm
2
)
GA 90 up to GA 315 60 Hz and GR 60 Hz, CSA/UL compressors
Compressor Supply voltage Cable size
GA 90 440 - 460V 2x (3xAWG00+AWG4)
GA 90 575 V 2x (3xAWG2+AWG6)
GA 110 440 - 460V 2x (3xAWG00+AWG3)
GA 110 575 V 2x (3xAWG1+AWG6)
GA 160 440 - 460V 2x (3xMCM250+AWG2) or (4X3XAWG2+AWG)
GA 160 575 V 2x(3XAWG000+AWG3)
GA 200 440 - 460V 2x (3xMCM500+AWG0)
Instruction book
68 2920 1475 06
