Operation EN MINI-REG, MIDI-REG, MAXI-REG
10
© Atlas Copco Industrial Technique AB - 9839 1513 01
Operation
Operating instructions
Setting the pressure
To set the pressure:
1. Pull the cap upwards.
2. Turn the cap.
3. Press the cap downwards. The pressure is now set.
Locking the pressure regulator valve
To prevent unauthorized changes in pressure setting, the setting cap of the pressure regulator valve can
be secured with a lock.
To lock the pressure regulator valve:
1. Press the cap down.
2. Turn the upper wheel of the cap to the locked position. The safety hooks will extend.
3. Hang a lock onto one of the hooks and close.
