6
The Compact user interface
Button Functionality
Question mark Pressing it will show RBU type (Au = Gold, Ag =
Silver etc), installed software release, connected
tool type, active Pset and Job
F Press F (Function key) to display functions. To
display function F1 press F once, to display
function F2 press F twice etc. Press Enter to
access and edit a function. When fi nished, press
F repeatedly to display result mode again (or
else it will take 30 seconds for the screen to
update automatically)
Note: The functionality is dependent on the RBU
version.
F1 / Ft Final target
F2 / tunE Torque tune factor (DS mode only)
F3 / tool Motor tuning. Press and hold the tool trigger
until ”done” is shown
F4 / Pset Change the Pset (in cases where this has been
enabled)
F5 / batS Set the batch size (0 to 99)
F6 / DISC Disconnect tool. Await ”Safe to disconnect”
before disconnecting
F7 / stun Sync motor tuning. The LH no. shows the
percentage of sync members already tuned.
The RH no. shows the progress of the ongoing
tuning
F8 / Stun Controller IP address. Restart the PF after
changing the address
AutoSet Start AutoSet, set the target torque and
make tightenings on the actual joint to let the
controller program the tightening parameters
