- 96 -
D1 Diode LS4 Level Switch - Engine Oil Level Overfill
Shutdown
TT1 Temperature Sensor - Compressor Oil
Temperature
D2 Diode
F1 Fuse ECM LS5 Level Switch - Coolant TT2 Temperature Sensor - Low Pressure
Element Temperature
F3 Fuse User Interface LT2 Level Sensor - Fuel Level
F4 Fuse Controller M1 Starter Motor TT3 Temperature Sensor - Medium Pressure
Element Temperature
F5 Fuse Flap Lock Solenoid N1 Detection module
F7 Fuse Fire Extinguisher N2 IR interface module TT4 Temperature Sensor - High Pressure
Element Temperature
F8 Fuse Fire Extinguisher N3 Flame detector
G2 Battery N4 Engine control module TT5 Temperature Sensor - Ambient
Temperature
G3 Battery PT1 Pressure Sensor - Air Discharge Pressure
H1-3 Lamp Internal Lights PT2 Pressure Sensor - Compressor Intercooler
Pressure 2
TT6 Temperature Sensor - Air Discharge
Temperature
H2 Lamp Engine Stop
H3 Lamp Engine Warning PT3 Pressure Sensor - Compressor Intercooler
Pressure 1
Y1 Solenoid Loading Valve
H4-5 Lamp Engine Warning Y2 Solenoid Oil Level Maintainer Valve
H5 Lamp Maintenance PT4 Pressure Sensor - Compressor Oil Pressure Y3 Refinery Equipment - Air Shut-off Valve
H6 Horn R1 Resistor 4K7 Y4 Solenoid Blow-off Valve
H7 Lamp Wait-to-start S1 Battery Switch Y6 Solenoid Automatic Actuator
K0 Starter Motor Relay S2 Emergency Stop Y7 Solenoid Automatic Actuator
K1 Auxiliary Starter Relay S3 Emergency Stop
K4 Solid State Relay S5 External Fuel Supply Switch
LS1 Level Switch - Engine Oil Level Full S6 Internal Lights On/Off Switch
LS2 Level Switch - Engine Oil Level Warning S7 Pressure Switch
(for manual actuator)
LS3 Level Switch - Engine Oil Level Shutdown
