Atlas Copco QAS 500 Volvo S2A APP - Regulation

- 51 -
Regulation
2511 Kp
0.0 s – 60.0 s
2512 Ti
0.0 s – 60.0 s
2513 Td
0.0 s – 2.0 s
2531 Kp
0.0 s – 60.0 s
2532 Ti
0.0 s – 60.0 s
2533 Td
0.0 s – 2.0 s
2541 Kp
0.0 s – 60.0 s
2542 Ti
0.0 s – 60.0 s
2543 Td
0.0 s – 2.0 s
2544 Pw
0.0% – 100.0%
2551 Offset
0.0% – 100.0%
2561 Deadband
1.0% – 100.0%
2562 Delay
10.0 s – 300.0 s
2563 Output A
Not Used – Option dependent
2564 Output B
Not Used – Option dependent
2611 Ramp
1.0 %/s – 20.0 %/s
2612 Point
1.0% – 100.0%
2613 Delay
0.0 s – 9900 s
2621 Ramp
1.0 %/s – 20.0 %/s
2622 Breaker Open
1.0% – 20.0%
2631 Delay
0.0 s – 60.0 s
2632 Output A
Not Used – Option dependent
2633 Output B
Not Used – Option dependent
2634 Enable
Off – On
2635 Failclass
Alarm (1) – Trip MB (6)
2641 Kp
0.0 s – 60.0 s
2642 Ti
0.0 s – 60.0 s
2643 Td
0.0 s – 2.0 s
2651 Kp
0.0 s – 60.0 s
2652 Ti
0.0 s – 60.0 s
2653 Td
0.0 s – 2.0 s
2661 Kp
0.0 s – 60.0 s
2662 Ti
0.0 s – 60.0 s
2663 Td
0.0 s – 60.0 s
2664 Qw
0.0% – 100.0%
2671 Offset
0.0% – 100.0%
2681 Deadband
1.0% – 100.0%
2682 Delay
10.0 s – 300.0 s
2683 Output A
Not Used – Option dependent
2684 Output B
Not Used – Option dependent
2741 Delay
0.0 s – 9900.0 s
2742 Output A
Not Used – Option dependent
2743 Output B
Not Used – Option dependent
2744 Enable
Off – On
2901 Type
Intern – Extern act – Extern pass
2902 Droop
0.0% – 20.0%
2903 EA-
80.0% – 110.0%
2904 EA+
90.0% – 130.0%
2905 EP-
0.0mA
2905 EP+
20.0mA
2911 Type
Intern – Extern act – Extern pass
2912 Droop
0.0% – 20.0%
2913 EA-
80.0% – 110.0%
2914 EA+
90.0% – 130.0%
2915 EP-
-20.0mA
2915 EP+
20.0mA
2510 f control 2620 Power ramp down 2680 AVR reg. fail
2740 Delay reg.
2900 f - Regulation
2910 U - Regulation
2630 Deload error
2640 U control
2650 Q control
2660 Q load sh. ctrl
2670 Analogue AVR offset
2530 P control
2540 P load sh. ctrl
2550 Analogue GOV
2560 GOV reg. fail
2610 Power ramp up
