Atlas Copco TPS Control User Manual

TPS Control EN User guide
© Atlas Copco Industrial Technique AB - 9836 5819 01
41
Format label data
Parameter name Description Range/Values
Control length Defines the length of the barcode label. Variable, 1-53
Default: 8
Number of STX
chars
Sets the number of prefix characters. 0-4
Default: 0
Character code
STX1-STX4
Only visible if Number of STX chars = 1-4.
Number of ETX
chars
Sets the number of postfix characters 0-4
Default: 2
Character code
ETX1-ETX4
Only visible if Number of ETX chars = 1-4.
Id1 Length Sets the number of characters used for the part of the
barcode defined as Id1
0-32
Default: 0
Id1 position Position of first character for reporting string Id1 (ex-
tracted from the Barcode)
1-128
Default: 1
Counted from Id1 position to be counted from; either the head or the
tail of the barcode string
head, tail
Default: head
Id2 Length Sets the number of characters used for the part of the
barcode defined as Id2
0-32
Default: 0
Id2 position Position of first character for reporting string Id2 (ex-
tracted from the Barcode)
1-128
Default: 1
Counted from Id2 position to be counted from; either the head or the
tail of the barcode string
head, tail
Default: head
Parameter name Description Range/Values
Control length Defines the length of the barcode label. Variable, 1-53
Default: 8
Number of STX
chars
Sets the number of prefix characters. 0-4
Default: 0
Character code
STX1-STX4
Only visible if Number of STX chars = 1-4.
Number of ETX
chars
Sets the number of postfix characters 0-4
Default: 2
Character code
ETX1-ETX4
Only visible if Number of ETX chars = 1-4.
Id1 Length Sets the number of characters used for the part of the
barcode defined as Id1
0-32
Default: 0
Id1 position Position of first character for reporting string Id1 (ex-
tracted from the Barcode)
1-128
Default: 1
Counted from Id1 position to be counted from; either the head or the
tail of the barcode string
head, tail
Default: head
Id2 Length Sets the number of characters used for the part of the
barcode defined as Id2
0-32
Default: 0
Id2 position Position of first character for reporting string Id2 (ex-
tracted from the Barcode)
1-128
Default: 1
