User guide EN TPS Control
8
© Atlas Copco Industrial Technique AB - 9836 5819 01
PIN Signal I/O Port 1 Signal I/O Port 2 Description
1 GND 24 V GND 24 V
2 OUT 1 OUT 7 Output, positive switching
24V, max 0.7 A, short-cir-
cuit proof
3 OUT 2 OUT 8 Output, positive switching
24V, max 0.7 A, short-cir-
cuit proof
4 OUT 3 OUT 9 Output, positive switching
24V, max 0.7 A, short-cir-
cuit proof
5 IN 2 IN 12 Digital input 16-32 volt
6 IN 4 IN 14 Digital input 16-32 volt
7 GND 24 V GND 24 V
8 IN 6 IN 16 Digital input 16-32 volt
9 IN 9 IN 19 Digital input 16-32 volt
10 OUT 4 OUT 10 Output, positive switching
24V, max 0.7 A, short-cir-
cuit proof
11 OUT 5 OUT 11 Output, positive switching
24V, max 0.7 A, short-cir-
cuit proof
12 OUT 6 OUT 12 Output, positive switching
24V, max 0.7 A, short-cir-
cuit proof
13 GND 24 V GND 24 V
14 +24 V +24 V
15 GND 24 V GND 24 V
16 GND 24 V GND 24 V
17 IN 1 IN 11 Digital input 16-32 volt
18 IN 3 IN 13 Digital input 16-32 volt
19 IN 5 IN 15 Digital input 16-32 volt
20 IN 7 IN 17 Digital input 16-32 volt
21 IN 8 IN 18 Digital input 16-32 volt
22 IN 10 IN 20 Digital input 16-32 volt
23 GND 24 V GND 24 V
24 GND 24 V GND 24 V
25 Not connected Not connected
ToolsTalk TPS
ToolsTalk TPS is a Microsoft Windows application that simplifies setup of the system. Only the main func-
tions needed for setting up the system are available in ToolsTalk TPS. The complete set of functions and
parameters is available in the TPS controller.
