Figure 57. Active Supply Current vs. Frequency
Figure 58. Active Supply Current vs. V
CC
0
5
10
15
20
25
0123456789101112131415
ACTIVE SUPPLY CURRENT vs. FREQUENCY
T = 25˚C
A
Frequency (MHz)
I
cc
(mA)
V
cc
= 5.5V
V
cc
= 5V
V
cc
= 2.7V
V
cc
= 3.0V
V
cc
= 3.3V
V
cc
= 3.6V
V
cc
= 4V
V
cc
= 4.5V
V
cc
= 6V
0
2
4
6
8
10
12
2 2.5 3 3.5 4 4.5 5 5.5 6
ACTIVE SUPPLY CURRENT vs. V
cc
FREQUENCY = 4 MHz
I
cc
(mA)
V
cc
(V)
T = 85˚C
A
T = 25˚C
A
