AT90S2313
19
Stack Pointer - SP
An 8-bit register at I/O address $3D ($5D) forms the stack pointer of the AT90S2313. 8 bits are used to address the
128 bytes of SRAM in locations $60 - $DF.
The Stack Pointer points to the data SRAM stack area where the Subroutine and Interrupt Stacks are located. This Stack
space in the data SRAM must be defined by the program before any subroutine calls are executed or interrupts are
enabled. The stack pointer must be set to point above $60. The Stack Pointer is decremented by one when data is pushed
onto the Stack with the PUSH instruction, and it is decremented by two when an address is pushed onto the Stack with
subroutine calls and interrupts. The Stack Pointer is incremented by one when data is popped from the Stack with the POP
instruction, and it is incremented by two when an address is popped from the Stack with return from subroutine RET or
return from interrupt RETI.
Reset and Interrupt Handling
The AT90S2313 provides 10 different interrupt sources. These interrupts and the separate reset vector, each have a sepa-
rate program vector in the program memory space. All the interrupts are assigned individual enable bits which must be set
(one) together with the I-bit in the status register in order to enable the interrupt.
The lowest addresses in the program memory space are automatically defined as the Reset and Interrupt vectors. The
complete list of vectors is shown in Table 2. The list also determines the priority levels of the different interrupts. The lower
the address the higher is the priority level. RESET has the highest priority, and next is INT0 - the External Interrupt Request
0, etc.
Bit 76543210
$3D ($5D) SP7 SP6 SP5 SP4 SP3 SP2 SP1 SP0 SPL
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
Table 2. Reset and Interrupt Vectors
Vector No. Program Address Source Interrupt Definition
1 $000 RESET Hardware Pin, Power-on Reset and Watchdog Reset
2 $001 INT0 External Interrupt Request 0
3 $002 INT1 External Interrupt Request 1
4 $003 TIMER1 CAPT1 Timer/Counter1 Capture Event
5 $004 TIMER1 COMP1 Timer/Counter1 Compare Match
6 $005 TIMER1 OVF1 Timer/Counter1 Overflow
7 $006 TIMER0 OVF0 Timer/Counter0 Overflow
8 $007 UART, RX UART, RX Complete
9 $008 UART, UDRE UART Data Register Empty
10 $009 UART, TX UART, TX Complete
11 $00A ANA_COMP Analog Comparator
