Instruction Set Summary
Mnemonics Operands Description Operation Flags #Clocks
ARITHMETIC AND LOGIC INSTRUCTIONS
ADD Rd, Rr Add two Registers
Rd ← Rd + Rr
Z,C,N,V,H 1
ADC Rd, Rr Add with Carry two Registers
Rd ← Rd + Rr + C
Z,C,N,V,H 1
ADIW Rdl,K Add Immediate to Word
Rdh:Rdl ← Rdh:Rdl + K
Z,C,N,V,S 2
SUB Rd, Rr Subtract two Registers
Rd ← Rd − Rr
Z,C,N,V,H 1
SUBI Rd, K Subtract Constant from Register
Rd ← Rd − K
Z,C,N,V,H 1
SBIW Rdl,K Subtract Immediate from Word
Rdh:Rdl ← Rdh:Rdl − K
Z,C,N,V,S 2
SBC Rd, Rr Subtract with Carry two Registers
Rd ← Rd − Rr − C
Z,C,N,V,H 1
SBCI Rd, K Subtract with Carry Constant from Reg.
Rd ← Rd − K − C
Z,C,N,V,H 1
AND Rd, Rr Logical AND Registers
Rd ← Rd • Rr
Z,N,V 1
ANDI Rd, K Logical AND Register and Constant
Rd ← Rd • K
Z,N,V 1
OR Rd, Rr Logical OR Registers
Rd ← Rd v Rr
Z,N,V 1
ORI Rd, K Logical OR Register and Constant
Rd ← Rd v K
Z,N,V 1
EOR Rd, Rr Exclusive OR Registers
Rd ← Rd ⊕ Rr
Z,N,V 1
COM Rd One’s Complement
Rd ← $FF − Rd
Z,C,N,V 1
NEG Rd Two’s Complement
Rd ← $00 − Rd
Z,C,N,V,H 1
SBR Rd,K Set Bit(s) in Register
Rd ← Rd v K
Z,N,V 1
CBR Rd,K Clear Bit(s) in Register
Rd ← Rd • ($FF − K)
Z,N,V 1
INC Rd Increment
Rd ← Rd + 1
Z,N,V 1
DEC Rd Decrement
Rd ← Rd − 1
Z,N,V 1
TST Rd Test for Zero or Minus
Rd ← Rd • Rd
Z,N,V 1
CLR Rd Clear Register
Rd ← Rd ⊕ Rd
Z,N,V 1
SER Rd Set Register
Rd ← $FF
None 1
BRANCH INSTRUCTIONS
RJMP k Relative Jump
PC ← PC + k + 1
None 2
IJMP Indirect Jump to (Z)
PC ← Z
None 2
RCALL k Relative Subroutine Call
PC ← PC + k + 1
None 3
ICALL Indirect Call to (Z)
PC ← Z
None 3
RET Subroutine Return
PC ← STACK
None 4
RETI Interrupt Return
PC ← STACK
I4
CPSE Rd,Rr Compare, Skip if Equal
if (Rd = Rr) PC ← PC + 2 or 3
None 1 / 2
CP Rd,Rr Compare Rd
− Rr Z, N,V,C,H 1
CPC Rd,Rr Compare with Carry Rd
− Rr − C Z, N,V,C,H 1
CPI Rd,K Compare Register with Immediate Rd
− K Z, N,V,C,H 1
SBRC Rr, b Skip if Bit in Register Cleared
if (Rr(b)=0) PC ← PC + 2 or 3
None 1 / 2
SBRS Rr, b Skip if Bit in Register is Set
if (Rr(b)=1) PC ← PC + 2 or 3
None 1 / 2
SBIC P, b Skip if Bit in I/O Register Cleared
if (P(b)=0) PC ← PC + 2 or 3
None 1 / 2
SBIS P, b Skip if Bit in I/O Register is Set
if (R(b)=1) PC ← PC + 2 or 3
None 1 / 2
BRBS s, k Branch if Status Flag Set
if (SREG(s) = 1) then PC←PC + k + 1
None 1 / 2
BRBC s, k Branch if Status Flag Cleared
if (SREG(s) = 0) then PC←PC + k + 1
None 1 / 2
BREQ k Branch if Equal
if (Z = 1) then PC ← PC + k + 1
None 1 / 2
BRNE k Branch if Not Equal
if (Z = 0) then PC ← PC + k + 1
None 1 / 2
BRCS k Branch if Carry Set
if (C = 1) then PC ← PC + k + 1
None 1 / 2
BRCC k Branch if Carry Cleared
if (C = 0) then PC ← PC + k + 1
None 1 / 2
BRSH k Branch if Same or Higher
if (C = 0) then PC ← PC + k + 1
None 1 / 2
BRLO k Branch if Lower
if (C = 1) then PC ← PC + k + 1
None 1 / 2
BRMI k Branch if Minus
if (N = 1) then PC ← PC + k + 1
None 1 / 2
BRPL k Branch if Plus
if (N = 0) then PC ← PC + k + 1
None 1 / 2
BRGE k Branch if Greater or Equal, Signed
if (N ⊕ V= 0) then PC ← PC + k + 1
None 1 / 2
BRLT k Branch if Less Than Zero, Signed
if (N ⊕ V= 1) then PC ← PC + k + 1
None 1 / 2
BRHS k Branch if Half Carry Flag Set
if (H = 1) then PC ← PC + k + 1
None 1 / 2
BRHC k Branch if Half Carry Flag Cleared
if (H = 0) then PC ← PC + k + 1
None 1 / 2
BRTS k Branch if T Flag Set
if (T = 1) then PC ← PC + k + 1
None 1 / 2
BRTC k Branch if T Flag Cleared
if (T = 0) then PC ← PC + k + 1
None 1 / 2
BRVS k Branch if Overflow Flag is Set
if (V = 1) then PC ← PC + k + 1
None 1 / 2
BRVC k Branch if Overflow Flag is Cleared
if (V = 0) then PC ← PC + k + 1
None 1 / 2
BRIE k Branch if Interrupt Enabled
if (I = 1) then PC ← PC + k + 1
None 1 / 2
BRID k Branch if Interrupt Disabled
if (I = 0) then PC ← PC + k + 1
None 1 / 2
