AT90S4414/8515
98
DATA TRANSFER INSTRUCTIONS
MOV Rd, Rr Move Between Registers Rd
←
Rr None 1
LDI Rd, K Load Immediate Rd
←
KNone1
LD Rd, X Load Indirect Rd
←
(X) None 2
LD Rd, X+ Load Indirect and Post-Inc. Rd
←
(X), X
←
X + 1 None 2
LD Rd, - X Load Indirect and Pre-Dec. X
←
X - 1, Rd
←
(X) None 2
LD Rd, Y Load Indirect Rd
←
(Y) None 2
LD Rd, Y+ Load Indirect and Post-Inc. Rd
←
(Y), Y
←
Y + 1 None 2
LD Rd, - Y Load Indirect and Pre-Dec. Y
←
Y - 1, Rd
←
(Y) None 2
LDD Rd,Y+q Load Indirect with Displacement Rd
←
(Y + q) None 2
LD Rd, Z Load Indirect Rd
←
(Z) None 2
LD Rd, Z+ Load Indirect and Post-Inc. Rd
←
(Z), Z
←
Z+1 None 2
LD Rd, -Z Load Indirect and Pre-Dec. Z
←
Z - 1, Rd
←
(Z) None 2
LDD Rd, Z+q Load Indirect with Displacement Rd
←
(Z + q) None 2
LDS Rd, k Load Direct from SRAM Rd
←
(k) None 2
ST X, Rr Store Indirect (X)
←
Rr None 2
ST X+, Rr Store Indirect and Post-Inc. (X)
←
Rr, X
←
X + 1 None 2
ST - X, Rr Store Indirect and Pre-Dec. X
←
X - 1, (X)
←
Rr None 2
ST Y, Rr Store Indirect (Y)
←
Rr None 2
ST Y+, Rr Store Indirect and Post-Inc. (Y)
←
Rr, Y
←
Y + 1 None 2
ST - Y, Rr Store Indirect and Pre-Dec. Y
←
Y - 1, (Y)
←
Rr None 2
STD Y+q,Rr Store Indirect with Displacement (Y + q)
←
Rr None 2
ST Z, Rr Store Indirect (Z)
←
Rr None 2
ST Z+, Rr Store Indirect and Post-Inc. (Z)
←
Rr, Z
←
Z + 1 None 2
ST -Z, Rr Store Indirect and Pre-Dec. Z
←
Z - 1, (Z)
←
Rr None 2
STD Z+q,Rr Store Indirect with Displacement (Z + q)
←
Rr None 2
STS k, Rr Store Direct to SRAM (k)
←
Rr None 2
LPM Load Program Memory R0
←
(Z) None 3
IN Rd, P In Port Rd
←
PNone1
OUT P, Rr Out Port P
←
Rr None 1
PUSH Rr Push Register on Stack STACK
←
Rr None 2
POP Rd Pop Register from Stack Rd
←
STACK None 2
BIT AND BIT-TEST INSTRUCTIONS
SBI P,b Set Bit in I/O Register I/O(P,b)
←
1None2
CBI P,b Clear Bit in I/O Register I/O(P,b)
←
0None2
LSL Rd Logical Shift Left Rd(n+1)
←
Rd(n), Rd(0)
←
0 Z,C,N,V 1
LSR Rd Logical Shift Right Rd(n)
←
Rd(n+1), Rd(7)
←
0 Z,C,N,V 1
ROL Rd Rotate Left Through Carry Rd(0)
←
C,Rd(n+1)
←
Rd(n),C
←
Rd(7) Z,C,N,V 1
ROR Rd Rotate Right Through Carry Rd(7)
←
C,Rd(n)
←
Rd(n+1),C
←
Rd(0) Z,C,N,V 1
ASR Rd Arithmetic Shift Right Rd(n)
←
Rd(n+1), n=0..6 Z,C,N,V 1
SWAP Rd Swap Nibbles Rd(3..0)
←
Rd(7..4),Rd(7..4)
←
Rd(3..0) None 1
BSET s Flag Set SREG(s)
←
1 SREG(s) 1
BCLR s Flag Clear SREG(s)
←
0 SREG(s) 1
BST Rr, b Bit Store from Register to T T
←
Rr(b) T 1
BLD Rd, b Bit load from T to Register Rd(b)
←
TNone1
SEC Set Carry C
←
1C1
CLC Clear Carry C
←
0 C 1
SEN Set Negative Flag N
←
1N1
CLN Clear Negative Flag N
←
0 N 1
SEZ Set Zero Flag Z
←
1Z1
CLZ Clear Zero Flag Z
←
0 Z 1
SEI Global Interrupt Enable I
←
1I1
CLI Global Interrupt Disable I
←
0 I 1
SES Set Signed Test Flag S
←
1S1
CLS Clear Signed Test Flag S
←
0 S 1
SEV Set Twos Complement Overflow. V
←
1V1
CLV Clear Twos Complement Overflow V
←
0 V 1
SET Set T in SREG T
←
1T1
CLT Clear T in SREG T
←
0 T 1
SEH Set Half Carry Flag in SREG H
←
1H1
CLH Clear Half Carry Flag in SREG H
←
0 H 1
NOP No Operation None 1
SLEEP Sleep (see specific descr. for Sleep function) None 3
WDR Watchdog Reset (see specific descr. for WDR/timer) None 1
Instruction Set Summary (Continued)
Mnemonics Operands Description Operation Flags #Clocks
