Instruction Set Summary
Mnemonics Operands Description Operation Flags #Clocks
ARITHMETIC AND LOGIC INSTRUCTIONS
ADD Rd, Rr Add two Registers Rd
←
Rd + Rr Z,C,N,V,H 1
ADC Rd, Rr Add with Carry two Registers Rd
←
Rd + Rr + C Z,C,N,V,H 1
ADIW Rdl,K Add Immediate to Word Rdh:Rdl
←
Rdh:Rdl + K Z,C,N,V,S 2
SUB Rd, Rr Subtract two Registers Rd
←
Rd - Rr Z,C,N,V,H 1
SUBI Rd, K Subtract Constant from Register Rd
←
Rd - K Z,C,N,V,H 1
SBC Rd, Rr Subtract with Carry two Registers Rd
←
Rd - Rr - C Z,C,N,V,H 1
SBCI Rd, K Subtract with Carry Constant from Reg. Rd
←
Rd - K - C Z,C,N,V,H 1
SBIW Rdl,K Subtract Immediate from Word Rdh:Rdl
←
Rdh:Rdl - K Z,C,N,V,S 2
AND Rd, Rr Logical AND Registers Rd
←
Rd
•
Rr Z,N,V 1
ANDI Rd, K Logical AND Register and Constant Rd
←
Rd
•
K Z,N,V 1
OR Rd, Rr Logical OR Registers Rd
←
Rd v Rr Z,N,V 1
ORI Rd, K Logical OR Register and Constant Rd
←
Rd v K Z,N,V 1
EOR Rd, Rr Exclusive OR Registers Rd
←
Rd
⊕
Rr Z,N,V 1
COM Rd One’s Complement Rd
←
$FF
−
Rd Z,C,N,V 1
NEG Rd Two’s Complement Rd
←
$00
−
Rd Z,C,N,V,H 1
SBR Rd,K Set Bit(s) in Register Rd
←
Rd v K Z,N,V 1
CBR Rd,K Clear Bit(s) in Register Rd
←
Rd
•
($FF - K) Z,N,V 1
INC Rd Increment Rd
←
Rd + 1 Z,N,V 1
DEC Rd Decrement Rd
←
Rd
−
1 Z,N,V 1
TST Rd Test for Zero or Minus Rd
←
Rd
•
Rd Z,N,V 1
CLR Rd Clear Register Rd
←
Rd
⊕
Rd Z,N,V 1
SER Rd Set Register Rd
←
$FF None 1
BRANCH INSTRUCTIONS
RJMP k Relative Jump PC
←
PC + k + 1 None 2
IJMP Indirect Jump to (Z) PC
←
Z None 2
RCALL k Relative Subroutine Call PC
←
PC + k + 1 None 3
ICALL Indirect Call to (Z) PC
←
ZNone3
RET Subroutine Return PC
←
STACK None 4
RETI Interrupt Return PC
←
STACK I 4
CPSE Rd,Rr Compare, Skip if Equal if (Rd = Rr) PC
←
PC + 2 or 3 None 1 / 2 / 3
CP Rd,Rr Compare Rd
−
Rr Z, N,V,C,H 1
CPC Rd,Rr Compare with Carry Rd
−
Rr
−
C Z, N,V,C,H 1
CPI Rd,K Compare Register with Immediate Rd
−
K Z, N,V,C,H 1
SBRC Rr, b Skip if Bit in Register Cleared if (Rr(b)=0) PC
←
PC + 2 or 3 None 1 / 2 / 3
SBRS Rr, b Skip if Bit in Register is Set if (Rr(b)=1) PC
←
PC + 2 or 3 None 1 / 2 / 3
SBIC P, b Skip if Bit in I/O Register Cleared if (P(b)=0) PC
←
PC + 2 or 3 None 1 / 2 / 3
SBIS P, b Skip if Bit in I/O Register is Set if (P(b)=1) PC
←
PC + 2 or 3 None 1 / 2 / 3
BRBS s, k Branch if Status Flag Set if (SREG(s) = 1) then PC
←
PC+k + 1 None 1 / 2
BRBC s, k Branch if Status Flag Cleared if (SREG(s) = 0) then PC
←
PC+k + 1 None 1 / 2
BREQ k Branch if Equal if (Z = 1) then PC
←
PC + k + 1 None 1 / 2
BRNE k Branch if Not Equal if (Z = 0) then PC
←
PC + k + 1 None 1 / 2
BRCS k Branch if Carry Set if (C = 1) then PC
←
PC + k + 1 None 1 / 2
BRCC k Branch if Carry Cleared if (C = 0) then PC
←
PC + k + 1 None 1 / 2
BRSH k Branch if Same or Higher if (C = 0) then PC
←
PC + k + 1 None 1 / 2
BRLO k Branch if Lower if (C = 1) then PC
←
PC + k + 1 None 1 / 2
BRMI k Branch if Minus if (N = 1) then PC
←
PC + k + 1 None 1 / 2
BRPL k Branch if Plus if (N = 0) then PC
←
PC + k + 1 None 1 / 2
BRGE k Branch if Greater or Equal, Signed if (N
⊕
V= 0) then PC
←
PC + k + 1 None 1 / 2
BRLT k Branch if Less Than Zero, Signed if (N
⊕
V= 1) then PC
←
PC + k + 1 None 1 / 2
BRHS k Branch if Half Carry Flag Set if (H = 1) then PC
←
PC + k + 1 None 1 / 2
BRHC k Branch if Half Carry Flag Cleared if (H = 0) then PC
←
PC + k + 1 None 1 / 2
BRTS k Branch if T Flag Set if (T = 1) then PC
←
PC + k + 1 None 1 / 2
BRTC k Branch if T Flag Cleared if (T = 0) then PC
←
PC + k + 1 None 1 / 2
BRVS k Branch if Overflow Flag is Set if (V = 1) then PC
←
PC + k + 1 None 1 / 2
BRVC k Branch if Overflow Flag is Cleared if (V = 0) then PC
←
PC + k + 1 None 1 / 2
BRIE k Branch if Interrupt Enabled if ( I = 1) then PC
←
PC + k + 1 None 1 / 2
BRID k Branch if Interrupt Disabled if ( I = 0) then PC
←
PC + k + 1 None 1 / 2
