1-13
d. Headmount/Helmet Mount Adapter
This item (Figure 1.1.) is attached to the monocular to allow its use
with the headmount or helmet mount. It allows mounting in front of
the left or right eye.
e. Weapon Mount
The weapon mount (Figure 1.1.) adapts the monocular to the re-
ceiver rail as configured for the modular weapon system kit.
The carrying case (Figure 1.3.) is provided for transportation and
protection of the monocular, headmount, battery and accesso-
ries. Two slide keepers are provided for belt attachment and three
D-rings for shoulder and leg strap attachment. A carrying case
strap is also provided which can be attached to the two D-rings on
the back of the carrying case.
g. Shipping and Storage Case
The NVMPS is supplied in a shipping and storage case
(Figure 1.3.).
The following tables provide information pertaining to the opera-
tional, electrical, mechanical, optical, and environmental charac-
teristics for the monocular.
ITEM LIMITS
Diopter Focus +2 to – 6 diopters
Objective Focus 25 cm to infinity
ITEM DATA
Power Source Battery (1.5 Vdc max ea.)
Battery Requirements
1 AA Alkaline or
1 AA 1.5 Vdc Lithium L91
