2-2
INDICATORS
NOTE
The MUNVM is designed to adjust for different users and cor-
rects for most differences in eyesight. The controls and indicators
for the MUNVM are shown in Figure 2.1., which are described in
Table 2.1.
NOTE
The gain control is not present in 6015 or PVS-14NG model.
NOTE
ON-
BATTERY POLARITY
INDICATORS (HIDDEN)
HIGH LIGHT
CUT-OFF
OBJECTIVE
FOCUS
IR LENS
LATCH
DIOPTER ADJUST-
MENT
EYE RELIEF
ADJUSTMENT
GAIN
CONTROL
