met mount adapter that fits into a groove on the monocular. Make
sure the boss on the adapter fits into the groove on the monocular.
HELMET
(1) Remove the helmet mount from the carrying case. Refer to Fig-
ure 2.12. for helmet mount features.
(2) Press the release (Figure 2.13.) to remove the mount from the
helmet mount bracket.
(3) Make sure the strap is laced onto the helmet mount bracket as
shown in Figure 2.13.
strap over the top of the helmet center (see Figure 2.14).
LATCH
ALIGNMENT BOSS
(HIDDEN)
ALIGNMENT BOSS
GROOVE
