2-31
(2) Screw in the thumbscrew to secure the monocular to the weap-
on mount.
(3) Loosen the clamping knob on the weapon mount. Position the
weapon mount with the monocular onto the weapon’s mounting rail.
Tighten by turning the clamping knob.
NOTE
-
(4) Check the position of the monocular by holding the weapon in
your normal firing position. Adjust the fore/aft position of the mon-
ocular as necessary by loosening the clamping knob and reposi-
tioning the weapon mount on the weapon’s mounting rail.
CAUTION
helmet mount will result in inaccurate compass readings. The
so will result in inaccurate compass readings.
NOTE
(1) If the sacrificial window or objective lens cap is in place, remove it.
(2) Turn monocular on.
(3) Rotate the objective lens focus completely counterclockwise
(while looking through the monocular).
NOTE
compass to fit properly.
