3-5

MALFUNCTION TEST OR INSPECTION CORRECTIVE ACTION

14. Compass display is not clear. Visual. Make sure the monocular is fo-

cused for infinity. If so, and com-

pass display is still not clear, refer

to higher level of maintenance.

15. Monocular does not cut off

when exposed to high light.

Visual.

Perform the following test under

daylight or bright room light (not

fluorescent light).

Place the objective lens cap on

the objective lens. Turn monocu-

lar ON and observe that it cuts

off within 70 ±30 seconds after

energized.

Turn monocular OFF and then

ON to reenergize monocular.

If damaged, refer to higher level

of maintenance.
