OPERATOR AND SAFETY MANUAL
1NO0035UK-05
Zebra 16
41
4.6.3 SLINGING – USING A CRANE
To lift the machine using a crane, the machine must be in parking – storage position as
described in Section 4.5 with the structure turned 90°.
Remove from the machine everything that could present a falling hazard.
Use a hoist adapted to the weight and dimensions of the machine.
Attach the slings to the 4 lifting points of the machine as represented on the drawing below.
2720
2200
