ATN Zebra 16 Operator's And Safety Manual

OPERATOR AND SAFETY MANUAL
42
1NO0035UK-05
Zebra 16
DANGER
IF THE ALARM SOUNDS STOP ALL
OPERATIONS IMMEDIATELY.
RETRACT THE TELESCOPE THEN
FULLY LOWER THE PLATFORM AND
RETURN THE MACHINE TO LEVEL
GROUNDS AGAIN BEFORE RAISING
THE WORK PLATFORM AGAIN
DANGER
NEVER PLACE ANY OBJECTS ON THE
TILT SENSOR.
S
S
S
e
e
e
c
c
c
t
t
t
i
i
i
o
o
o
n
n
n
5
5
5
.
.
.
S
S
S
A
A
A
F
F
F
E
E
E
T
T
T
Y
Y
Y
D
D
D
E
E
E
V
V
V
I
I
I
C
C
C
E
E
E
S
S
S
5.1. TILT SENSOR
The tilt sensor in the ground control station
constantly measures the machine's tilt.
-NOTE-
This device must not guide how the machine
is used. Do not raise the platform or move
with the platform on inclines, uneven or
loose surfaces.
• When the structure is in low position, the
light comes on to indicate that the machine's
tilt level is too high for the platform to be
raised.
• When the structure is raised, the tilt light
comes on and an alarm sounds when the
maximum tilt authorised is reached.
The alarm indicates that the machine has
reached its stability limit.
Different movement cutout levels may be configured if the acceptable tilt is exceeded.
• Mode 1:
- Drive movement cutout when the maximum tilt is reached.
- Engine high speed cutout for the structure movements.
• Mode 2:
- Drive movement cutout when the maximum tilt authorised is reached.
- Engine high speed cutout for the structure movements.
- Structure movement speed reduction.
- Telescope extension cutout
- Arm 2 movement and orientation cutout until the telescope is taken back in.
- Combined movements prohibited.
• Mode 3:
- Drive movement cutout when the maximum tilt authorised is reached.
- Engine high speed cutout for the structure movements.
- Structure movement speed reduction.
- Telescope extension cutout
- Arm 1 and 2 elevation cutout.
- Arm 2 lower and orientation cutout until the telescope is taken back in.
- Combined movements prohibited.
• Mode 4 (CAUTION, this mode does not correspond to the EC standard):
- No movement cutout.
- Engine high speed cutout for the structure movements.
