ATN Zebra 16 Operator's And Safety Manual

OPERATOR AND SAFETY MANUAL
54
1NO0035UK-05
Zebra 16
S
S
S
e
e
e
c
c
c
t
t
t
i
i
i
o
o
o
n
n
n
8
8
8
.
.
.
C
C
C
O
O
O
N
N
N
T
T
T
R
R
R
O
O
O
L
L
L
M
M
M
O
O
O
D
D
D
U
U
U
L
L
L
E
E
E
The command circuit control module is located inside the command unit on the ground. This
interface is used to:
• View the diesel engine's operating parameters.
• View the status of the machine's different sensors and actuators.
• Store and display the machine's operating anomalies and faults.
• Programme the maintenance intervals.
• Diagnose a command circuit fault.
• Modify some of the machine's operating parameters.
• Display the manufacturer's details.
The operating parameters may only be accessed with an access code. These parameters may
only be modified by qualified and authorised personnel.
8.1. WELCOME SCREEN
The following screen is displayed when the machine is powered up:
1- Machine model and serial number
2- Date / time,
3- System status: System OK / Error active.
4- Light - System fault.
5- Lights - Faults:
(2)
(7)
(3)
(4)
(8)
(11)
(6)
(9)
(5)
(12)
(10)
(1)
