InputX (RGB)
InputX (RGB) 1/3
Parameter name Range Unit Remarks
Format
[InHsize]x[InVsize]/[InFrameRate][i/P/sF/
Hz]
Displays the input signal format.
Format Fix
Off
,On
When set to on, input format detection is disabled, and the input
format fixed.
Fix Format
2K/59p/50p/29p/25p/24p/23p,1080/59p/50
p/29p/25p/24p/23p,
1080/59i
/50i,720/
59p/50p,480/59p,576/50p,480/59i,576/
50i
Sets the input format to be used.
Color Space
Auto
,RGB,YCC(SD),YCC(HD) Input color space can be set to auto-detect or a specific setting.
Analog Timing Adjust RESET
Adjusts the onscreen position of the PC RGB input signal.
Disabled when a video analog component signal is input.
H position -100,,
0
,,+100 pixel Adjusts the horizontal onscreen position of the PC RGB input signal.
V position -100,,
0
,,+100 line Adjusts the vertical onscreen position of the PC RGB input signal.
Frequency -100,,
0
,,+100 pixel Adjusts the sampling frequency of the PC RGB input signal.
Phase -16,,
0
,,+16 Adjusts the sampling phase of the PC RGB input signal.
LOS Threshold
0,,
5
,,10
Sets the threshold for loss-of-signal action.
The lower the value the higher the sensitivity, and the higher the
value the better the system will resist noise.
