20
Figure 11 Split diagram of upper protective glass and focusing lens on HW980
■ Direction of protective glass drawer and focusing lens drawer:
20.55 sealing ring
Protective glass D20X3
Focusing lens drawer
20.55 sealing ring
Focusing lens D20-F150
Please pay attention to the direction
when inserting the drawer.
