Au3Tech HW980 - Page 31

31
(The output amplitude
can be configured)
3
0
～
10V(0
～
4V)
0～10V\0～4V analog output
signal
(The output range can be
configured)
4
AGND
3
CON2
OUT
1
LA-
EN+
DC24V laser enable
output signal
2
LA-EN-
3
GAS+
output connected to solenoid
valve to control blowing
(Drive current Max 2A)
4
GAS-
4
CON3
IN
1
LA-
ALM+
Laser alarm input port
(DC24V high level valid)
）
2
LA-
ALM-
3
LA-
Red+
Red light indicating control signal
(DC24V high level
effective)
4
LA-
Red-
5
CON4
IN/OU
T
1
RS232-
R
Reserved
2
RS232-
T
OUT
3
NOP
Reserved
4
GND
