Fast Track Guide 3. Configuring the Mediant 1000
Version 5.0 15 October 2006
3.2 Restoring Networking Parameters to their Initial State
You can use the ‘Reset’ button located on the Mediant 1000 chassis to restore the Mediant 1000
networking parameters to their factory default values (listed in Table
3-1) and to reset the case-
sensitive username and password.
Note that the Mediant 1000 returns to the software version burned in flash. Therefore, you must
load your previously backed-up
ini file or the default ini file (received with the software kit) to set
them to their correct values.
¾ To restore networking parameters to their initial state, take these 3
steps:
1. Press in the ‘Reset’ button uninterruptedly for a duration of more than six seconds; the
gateway is restored to its factory settings (username: “Admin”, password: “Admin”).
2. Assign the Mediant 1000 an IP address (refer to Section 3.1 on page 12).
3. Load your previously backed-up ini file or the default ini file (received with the software kit).
To load the
ini file via the Embedded Web Server, refer to Section 5 on page 28.
3.3 Accessing the Embedded Web Server
¾ To access the Embedded Web Server, take these 4 steps:
1. Open a standard Web-browsing application such as Microsoft™ Internet Explorer™ (Version
6.0 and higher) or Netscape™ Navigator™ (Version 7.2 and higher).
2. In the URL field, specify the IP address of the gateway (e.g., http://10.1.10.10); the
Embedded Web Server’s ‘Enter Network Password’ screen appears, shown in Figure
3-2.
Figure 3-2: 'Enter Network Password' Screen
3. Enter the username (default: “Admin”), and password (default: “Admin”). Note that the ‘User
Name’ and ‘Password’ fields are case-sensitive.
4. Click OK; the ‘Quick Setup’ screen opens, shown in Figure 3-3 (MEGACO), Figure 3-4
(H.323), and Figure
3-5 (SIP).
